Infrared Reversing Camera, resolution 1920x1080P, wide angle 155°

AD-BGCM3

The right camera for you

AHD 1080P reversing camera is an essential accessory for any driver who wants safe, precise vehicle manoeuvring. With Full HD 1080P resolution and a wide viewing angle, this camera delivers clear, detailed images, eliminating blind spots and reducing the risk of collisions.




Whether you are parking in tight spaces or driving in poor visibility, AHD 1080P reversing camera gives you the assistance you need for a safer, more comfortable drive.

---

Key benefits:

Superior video quality - Clear, detailed images thanks to the resolution Full HD 1920x1080P

  Extended viewing angle – 155° horizontal and 90° vertical for optimal coverage

  Weather protection - Certification IP68 for water and dust resistance

  Broad compatibility - Works with allour car head units

---

📊 Technical specifications



Feature	Details
Signal	AHD 1080P / AHD 720P
Camera chipset	1/3 CMOS, 2 glass layers
Video resolution	Full HD 1920H × 1080V
TV system	AHD @ 25fps
Viewing angle	155° (horizontal), 90° (vertical)
Waterproofing	IP68 (water and dust resistant)
Rated voltage	12V DC
Operating voltage	6V - 24V
Connector	Mini 4 Pin
Control functions	AHD 1080P / AHD 720P signal switching

---

   Why our camera?

Superior clarity and resolution - The AHD camera delivers a more detailed image (720P or 1080P), while CVBS has a low resolution (480P), which makes details harder to make out.

Excellent night-time visibility - Even without LEDs, AHD uses a better sensor and delivers a clear image in low light, while CVBS relies on LEDs, which can create reflections and overexposed areas.

More natural colours and better contrast - The AHD camera reproduces colours more faithfully and offers improved contrast, which helps you pick out obstacles, unlike CVBS, whose image is washed out and noisy.

Compatible with HD screens - Modern navigation and multimedia systems support the AHD signal, giving a clear, distortion-free image, whereas CVBS cameras are limited and can suffer interference or blurred images






---



Package contents

1x Reversing camera AHD 1080P /1x Connection cable Mini 4 Pin /  1x Instruction flyer
